【現貨商品2-3天到貨】

Keychron Q2 QMK 客製化機械鍵盤

KBKCQ2C1RED
$3,490.00

類型
顏色
軸體




完全組裝的版本包括:
  • 鍵盤PCB、外殼、鋼板。
  • 雙色 OSA PBT 鍵帽(包括 Mac 和 Windows 鍵帽)。
  • Gateron G Pro 軸體。

準成品套件版本不包括鍵帽和軸體。

Q2不能使用折扣代碼。

如果產品型號缺貨,請將您的電子郵件發送至「有貨時通知我」




旋鈕顏色可能與外殼略有不同(僅藍色和灰色),因為這些部件是單獨製造的。

Keychron Q2 65% Custom Mechanical Keyboard

Keychron Q2

Q2是一款完全可自訂的機械式鍵盤,佈局緊湊,可將您的打字體驗提升到一個新的水平。 Q2採用65%規格、全金屬機身和 double-gasket 設計,專為客製化體驗和優質打字舒適度而設計。

Keychron Q2 65% Custom Mechanical Keyboard
Features of Keychron Q2 QMK VIA 65% layout custom mechanical keyboard
客製化您的Q2

為您的Q2選擇鍵帽、軸體和更多配件

部分
將元素拖放到這裏

精心製作且結構緊湊

為了為您的辦公桌打造更小巧、更精緻的鍵盤,我們為您帶來了Q2。整機採用 6063 鋁材打造,經過CNC加工、拋光、陽極氧化、噴砂等24道製造工序,
打造出Q2這件藝術品。

Aluminum frame of Keychron Q2 QMK VIA 65% layout custom mechanical keyboard
Keychron Q2 65% Custom Mechanical Keyboard

全方位可自訂鍵盤

為了建造完全可自訂的鍵盤,我們設計的每個組件都能夠輕鬆組裝。因此,您可以自訂和調整您想要的每個元件。

Keychron Q2 QMK VIA custom mechanical keyboard with knob 65 percent layout and double gasket design and hot swappable Gateron G Pro switch US ISO UK layout or Barebone

Double-Gasket 設計

Double Gasket 設計是業界全新的創新結構。除了板上的墊圈外,我們還在頂殼和底殼之間添加了矽膠墊,以顯著減少金屬之間的聲音共振並降低受影響金屬的噪音。這種雙墊片結構可以讓鍵盤保持墊片結構的靈活性,並改善整體打字聲音。

Double Gasket Deign of Keychron Q2 65% Custom Mechanical Keyboard

可編程旋鈕

可自訂旋鈕旨在增強您的工作流程,讓您可以透過創新的 VIA 軟體輕鬆自訂您最喜歡的按鍵和巨集。

Rotary encoder function of Keychron Q2 QMK VIA 65% layout custom mechanical keyboard with rotary encoder knob version

您可以輕鬆地將Q2的旋鈕自訂為所需的按鍵或巨集命令,例如放大/縮小、調整螢幕亮度、畫筆大小、透明度、音量、選擇影片剪輯或照片或背光色調。

在 VIA 上編輯鍵盤配置

透過旋鈕控制器放大和縮小

部分
將元素拖放到這裏

OSA樣式雙色PBT鍵帽

對於新的雙色 PBT 鍵帽,我們建立了新的鍵帽樣式。它具有與 OEM 樣式相似的高度,並具有類似 SA 的形狀。我們將其命名為 OSA(OEM 球型)鍵帽。 PBT 鍵帽將提供出色的耐油性,增強打字手感,並防止圖案褪色。

OSA Profile Double-shot PBT Keycaps of Keychron Q2 65% Custom Mechanical Keyboard
部分
將元素拖放到這裏
Keychron Q2 65% Custom Mechanical Keyboard

在 macOS 和 Windows 之間切換佈局

Keychron Q2在設計時充分考慮了 Mac 用戶的體驗,同時仍保留了對 Windows 裝置的兼容性,配備了系統切換開關和一組適用於 Windows 和 macOS 系統的額外自訂鍵帽。現在您可以在鍵盤上儲存兩種不同的佈局,每個系統一種。

使用 QMK 和 VIA 自訂Q2

憑藉完整的 QMK 和 VIA 支持,您可以輕鬆編程和重新配置鍵盤上的每個按鍵。開源軟體意味著鍵盤佈局、快捷鍵、背光效果、甚至旋鈕等的無限可能性。全新超低功耗Arm Cortex-M4 32位元STM32L432 晶片功能強大,配備128K快存記憶體,將為開發人員提供更多彈性。

QMK VIA screen capture of Keychron Q2 Knob version

熱插拔支援

熱插拔插座安裝在 PCB 上,因此您無需焊接即可安裝或更換開關。 PCB 支援3針和5針 MX 機械開關。

RGB LED 下位燈

RGB 下位燈設計旨在從打字員的角度更好地照亮鍵盤背光,並安裝優質非透光 PBT 鍵帽。當使用者在鍵盤上安裝 OEM 或 Cherry 型替代鍵帽時,RGB下位燈也不會受到干擾。

Note: The Q2's top case has sharper corners to make it much more compatible with third-party keycaps.

Barebone US layout of Keychron Q2 QMK VIA 65% layout custom mechanical keyboard with rotary encoder knob version

出廠預潤 Gateron G Pro 軸體

對於優質打字體驗而言,每個細節都很重要。優化的模具具有更精確的定位和更少的晃動,肯定會改善您的指尖感受。
與出廠預潤的 Gateron G Pro 軸體搭配使用,可確保順暢的敲擊體驗。

Gateron G Pro Switch Features of Keychron Q2 65% Custom Mechanical Keyboard
All New Screw In PCB Stabilizers of Keychron Q2 65% Custom Mechanical Keyboard

全新旋入式
 PCB 衛星軸

旋入式設計增加了穩定性,並且更容易更改和升級。精密的製程使衛星軸更穩定、更少晃動。大鍵(空白鍵、Shift、Enter、刪除鍵)的打字體驗現在更加穩定和流暢。 Keychron Q2也支援第三方衛星軸,包括 Cherry 或 Durock。

正在尋找 ISO 佈局?

Q2 ISO 系列配備了完全組裝的鍵盤,包括🇬🇧英國、🇩🇪德語、🇩🇰🇫🇮🇮🇸🇳🇴🇸🇪北歐語系"ISO"選項適用於所有 ISO 國家(例如:🇮🇹義大利、🇵🇹葡萄牙語、🇭🇺匈牙利等),
以他們喜歡的語言和軸體建造帶鍵帽的鍵盤。

Keychron Q2 65% Custom Mechanical Keyboard

打字聲音測試

部分
將元素拖放到這裏

各種版本

Keychron Q2 65% Custom Mechanical Keyboard
部分
將元素拖放到這裏

盒子裡有什麼?

Keychron Q2 65% Custom Mechanical Keyboard
Keychron Q2 65% Custom Mechanical Keyboard

詳細配置

寬度121 mm
長度327.5 mm
前高20 mm  (不含鍵帽)
後高33.8 mm (不含鍵帽)
腳撐高度2.7 mm
角度6.5°
重量1645 g ± 10g (完全組裝版)
機身材質全CNC鋁材質
板材材質
傳輸速率1000Hz
鍵帽
(完全組裝版)
雙色 PBT 鍵帽,不透光,OSA 樣式
(OEM 高度,SA 形狀)
晶片Ultra-low-power Arm Cortex-M4 32-bit STM32L432 (128KB Flash)
軸體
Gateron G Pro (完全組裝版)
背光 下燈位 RGB LED
支援軸體可熱插拔(5針和3針)
衛星軸旋入式 PCB 衛星軸
連接方式Type-C
連接線
Type-C傳輸線 + Type-A to Type-C 轉接頭
部分
將元素拖放到這裏
Keychron Q2使用者指南

在常見問題解答部分了解有關 Keychron Q2的更多資訊,例如Q2快捷鍵、組裝Q2、
恢復出廠設定等。

All Keyboards
All Keyboards

Customer Reviews

Based on 266 reviews
74%
(197)
16%
(43)
5%
(12)
2%
(4)
4%
(10)
A
Alistair Lamb
Almost perfect.

Just here to echo another review:
"Only thing I would change would be a way that I can pause the animation to have a gradient of colour on the keyboard."

T
Tim Wat
Two mods, now solid

Purchased the fully assembled navy blue w Red switches for my work daily driver - on Win machines I prefer a 65%, while at home on a Mac I prefer 75% (which is why the home daily driver is a GMMK Pro). I prefer the heft of a full aluminum chassis, and have liked the other Keychrons I've purchased and tried.

Out of the box, the Q2 has nice heft. It's substantial, it feels serious. Fit and finish is first rate. Has more flex and give than the GMMK Pro, which I very much like. The OSA keycap profile is also quite nice, very much different than the spherical Drop MT3 I had been using at home, and after adjusting I prefer typing on it. The switch and keycap pullers are good quality, and there are thoughtful included items like allen screwdriver for the case screws and additional screws (yay!). So there's a lot to like just unboxing and plugging it in.

All that being said, my initial reservations were stabilizers and overall typic experience. The typing feel was just okay for me, sound profile not really pleasant. And those stabilizers, out of the box...nope. They are pre-lubed (with lube dripping down onto the PCB, I found), but clacky.

So the two mods I performed: 1) replaced the red switches with Gateron Phantom Yellows, and 2) band aid modded the stabilizers. This really cleaned up both the typing feel and the sound profile. No more clack, much more thock.

The vertical give of the Q2 and the lower-pitched sound profile is now much more pleasant than what I have on the home office driver, and I'm hoping the new GMMK Flex Kit that is arriving next week will get that closer to what I now have in the Q2.

I also realize all of this is pretty subjective...many of you will love the Q2 as-delivered, right out of the box. Others of us may want to disassemble and modify a bit, and for that, the Q2 offers lots of opportunities, as well as a very accessible and straightforward assembly process that makes modding easy.

All in all, I'm very pleased with the purchase, and can recommend the Q2 as both a great entry point board (many will leave it stock) and a good 65% platform for mods both subtle and extreme.

J
Jesse Musgrove
Best keyboard ive ever used

This is my first keyboard with lubed switches and it honestly feels so different from any other keyboard ive used. They are way smoother and easier to press and i would highly recommend getting the red switches with this keyboard. The build is very sturdy and the case is a very heavy metal and feels like quality. The OSA keycaps are just fine for me even though ive always been using normal keycaps, i also like the font. I have the shell white one and it looks beautiful with the RGB shining through. My only complaint is that the left shift is a bit heavier to press down than what im used to and i play a lot of shooting games. Other than that, this is a great keyboard.

C
C.
Great keyboard

Great keyboard - it's now my go-to. Solidly built with nice feeling key caps, and I love the knob.

I'm a programmer, so I spend all day typing. This keyboard has been great, and is one of the smallest I could find that still had the top-level functionality I need. (I don't like relying on layers for things I hit frequently, I have too many different keyboards to make learning new keys worth it)

J
J.
Such an amazing keyboard

It feels so good to type on with Gateron browns. Very quality feeling and the keycaps are professional looking. I'm not even going to mod it; buying some holy pandas and bringing it to work.
